APD - VK08N

	- Display the current status information - saving the menu data download function - Display the motor speed torque with a graph - Easy changing of mode menu data - Display function of Alarm status - Operation handling function by using communication protocol - Data editing gunction by using cimmumication-code - Auto Jog operation test function - PC Specifications : Window98, WindowXP

Model

External Dimension

Ratings and Characteristics

Servo Drive (APD-VK)		08N
Power Supply	Power Supply	Signal PhaseAC200~230[V] +10%-15%,
Power Supply	Frequency	50/60[Hz]
Applicable Motor	Voltage Current	3 Phase Sine Wave PWM driven AC Servo Motor
	Rated Current	3.9
	Max. Current	11.7
Encoder		Standard : Incremental 5V Line Driver 15선 2,500[P/R] SA Series Motor : 2,048[P/R]
Position Control mode	Input Frequency	500 [kpps] Line Driver, 200[kpps] Open Collector
	Input Pulse Type	A+BPhase, Forward/Reverse Pulse, Direction+Pulse[Line Driver, Open Cillector]
	Input Pulse	5[V] Line Drver,24[V] Open Collector
Speed Control mode	Range Of Speed Control	1:10,000
	Accel/Decel Time	Linear or SShape Accel/Desel, 0~10,000[ms],1[ms] Units can be set seperately
	Inside Communication	3 Different Speed Setting
Setting	Communication	Standard : RS232C, Option : RS485Max. 16 Axis
Setting	Option	Handy Loader
Embedded Function	Generative Braking	Standard Embedded[Operated at Servo Alarm or Servo OFF]
	Regenerative Braking	Standard Embedded
	Electronic Gear Ratio	99,999/99,999 Times of Commａnd Pulse is Possible
	Feedback Pulse Dividing	From 1to 16, Selection Division is possible/Sone Driver A/B/Z Phase, Open Collector Z Phase Output
	Contacts Logic	Selecting A/B contact (Input/Output Contacts) function
Monitor	Digital Display	Built in 7 - Segments[1Digits]
Monitor	Analong Output	DC 5[V]~ +5[V],2Channels [Speed, Torque, etc]
Protect Funstion	Items Displayed	Overcurrent, Overload,Overvoltage,Voltage shortagd, Overspeed, Wrong wiring, Encoder problem.
Protect Funstion	Momory Dapacity	Can save memory The alarm upto 20 times including the current alarm occurred
Ambient Environment	Temperature	0~50[℃]
	Humidity	Less than 90[%](Avoid Condensation)
	Atmoshere	indoors, No corrosive gas, Inflammable gas and fluid, Oil Mist, or dust
